Product thermal capacity: 1 – 20 t/h
Working pressure: 0.7-2 MPa
Available fuel: Natural gas, coke oven gas, biogas, diesel, heavy oil, light oil, crude oil, etc.
Available industries: Heat supplying, chemical, food, textile, printing and dyeing, cigarettes and tobacco, fodder, pharmacy, building materials, brewery, rubber, hospital etc.
Email: zhulin@zozen.com
WNS Series 6 Tph Boiler Introduction
The WNS series 6 tph boiler features a horizontal internal combustion wet-back design with a compact, well-structured layout. Incorporating advanced three-pass flue gas flow technology and an optimized combustion system, this boiler achieves thermal efficiency levels of up to 98%. Its exceptional efficiency helps significantly reduce energy consumption and operating costs. Constructed from high-quality materials that withstand high temperatures and corrosion, the 6 tph boiler delivers excellent durability and long service life while minimizing maintenance requirements.
This 6 tph boiler is equipped with a fully automated intelligent control system that enables real-time monitoring and remote operation. It continuously tracks operating parameters to ensure stable, safe, and efficient performance. Additionally, the boiler supports multiple fuel options—natural gas, light diesel, and heavy oil—enhancing its adaptability across various industrial applications.
Product Advantages
WNS Series 6 Tph Boiler Advantage
High Efficiency and Energy Saving: The WNS series 6 tph boiler achieves up to 98% thermal efficiency by utilizing a three-pass flue gas structure and a highly optimized combustion system. This ensures maximum heat transfer, minimizing fuel consumption and reducing overall energy costs.
Smart Control System: The integrated intelligent control system allows for real-time data monitoring and remote operation of the 6 tph boiler, enhancing operational safety, reliability, and user convenience.
Environmentally Friendly with Low Emissions: Equipped with a low-NOx burner, the 6 tph boiler minimizes pollutant emissions, ensuring compliance with strict environmental regulations and supporting sustainability initiatives.
Flexible Fuel Options and Broad Applicability: The 6 tph boiler is compatible with various fuels, including natural gas, light diesel, and heavy oil. Its versatility makes it ideal for industries such as food processing, chemical production, textiles, and general industrial heating.
WNS Series 6 Tph Boiler Specification
| Model | Rated steam capacity (t/h) | Rated working pressure (MPa) | Rated steam temperature (℃) | Feed water temperature (℃) | Maximum transport weight (t) | Maximum transport dimension (m) |
| WNS1-0.7-Q(Y) | 1 | 0.7 | 170 | 20 | 4.5 | 3.25×1.80×2.00 |
| WNS1-1.0-Q(Y) | 1 | 1.0 | 184 | 20 | 4.5 | 3.25×1.80×2.00 |
| WNS1.5-1.0-Q(Y) | 1.5 | 1.0 | 184 | 20 | 7.0 | 3.65×2.05×2.45 |
| WNS1.5-1.25-Q(Y) | 1.5 | 1.25 | 194 | 20 | 7.0 | 3.65×2.05×2.45 |
| WNS2-1.0-Q(Y) | 2 | 1.0 | 184 | 20 | 9.0 | 4.60×2.20×2.60 |
| WNS2-1.25-Q(Y) | 2 | 1.25 | 194 | 20 | 9.0 | 4.60×2.20×2.60 |
| WNS3-1.0-Q(Y) | 3 | 1.0 | 184 | 20 | 11.5 | 5.35×2.40×2.80 |
| WNS3-1.25-Q(Y) | 3 | 1.25 | 194 | 20 | 11.5 | 5.35×2.40×2.80 |
| WNS4-1.25-Q(Y) | 4 | 1.25 | 194 | 20 | 15.0 | 5.00×2.60×2.95 |
| WNS4-1.6-Q(Y) | 4 | 1.6 | 204 | 20 | 15.0 | 5.00×2.60×2.95 |
| WNS5-1.25-Q(Y) | 5 | 1.25 | 194 | 20 | 18.0 | 5.55×2.658×3.20 |
| WNS5-1.6-Q(Y) | 5 | 1.6 | 204 | 20 | 18.0 | 5.55×2.658×3.20 |
| WNS6-1.25-Q(Y) | 6 | 1.25 | 194 | 20 | 19.5 | 5.93×2.80×3.20 |
| WNS6-1.6-Q(Y) | 6 | 1.6 | 204 | 20 | 19.5 | 5.93×2.80×3.20 |
| WNS8-1.25-Q(Y) | 8 | 1.25 | 194 | 20 | 25.0 | 7.00×2.80×3.25 |
| WNS8-1.6-Q(Y) | 8 | 1.6 | 204 | 20 | 25.0 | 7.00×2.80×3.25 |
| WNS10-1.25-Q(Y) | 10 | 1.25 | 194 | 104 | 27.5 | 7.65×2.80×3.25 |
| WNS10-1.6-Q(Y) | 10 | 1.6 | 204 | 104 | 27.5 | 7.65×2.80×3.25 |
| WNS15-1.25-Q(Y) | 15 | 1.25 | 194 | 104 | 40.0 | 7.95×3.50×3.75 |
| WNS15-1.6-Q(Y) | 15 | 1.6 | 204 | 104 | 40.0 | 7.95×3.50×3.75 |
| WNS20-1.25-Q(Y) | 20 | 1.25 | 194 | 104 | 52.0 | 8.55×3.90×4.15 |
| WNS20-1.6-Q(Y) | 20 | 1.6 | 204 | 104 | 52.0 | 8.55×3.90×4.15 |
